Technical indicators:
|
Maximum working size
|
mm
|
island 8 "or160mm×160mmsquare
|
|
Working speed
|
r/min
|
100 - 2400
|
|
Anti clamp hand device
|
-
|
Standard
|
|
Other
Specifications
|
Power Supply
|
v
|
two-phaseac220v±Ten％
In addition to the above, the transformer needs to be configured
|
|
Power consumption
|
Processing time
|
kw
|
Zero point eight(reference value)
|
|
Warmer time
|
kw
|
Zero point two(reference value)
|
|
Compressed air supply pressure
|
Mpa
|
0.5 - 0.8
|
|
Maximum compressed air consumption
|
L/min（ANR）
|
Two hundred
|
|
DIwater pressure
|
Mpa
|
0.25 - 0.4
|
|
DIMaximum water consumption
|
L/min
|
Six
|
|
NTwopressure
|
Mpa
|
0.25 - 0.4
|
|
NTwoMaximum consumption
|
L/min
|
Two hundred（Max）
|
|
Exhaust air volume
|
mThree/min
|
Two
|
|
Equipment size (W×D×H）
|
mm
|
Four hundred×Six hundred×One thousand and two hundred（SixInches)
|
|
Equipment weight
|
kg
|
aboutOne hundred
|
Conditions of use:
1. please set the machine in a 20~25 C environment (the range of fluctuation is within + 1 c); the indoor humidity is less than 80%, and there is no condensation.
2. please use the air pressure dew point below -15 C, the residual oil is 0.1ppm, the filtration degree is above 0.01um/99.5, clean compressed air.
3., please control the water temperature of the cutting water at room temperature of +2 C (within the range of + 1 c), and the water temperature of the cooling water is the same as that of the room temperature (the fluctuation range is controlled at + 1 degrees Celsius).
4. please avoid the gravity impact of the equipment and any vibration threat from the outside world. In addition, please do not install the equipment near the blower, the vent, the high temperature device and the oil producing device.
5. please install the equipment in a waterproof floor and a place with drainage treatment.
6. please do the operation in strict accordance with the instructions of the company's products.
